Creation Analysis: Using 3D to Make 2D Style Scene(2)

Creation-Analysis-Using-3D-to-Make-2D-Style-Scene-1

As the leading cloud rendering services provider and GPU & CPU render farm, Fox Renderfarm is here to continue to share with you how to make 2D scene with 3D.

In this article, we still show the use of 3ds Max to create 2D animated movie-style scenes and will focus on explaining the Makoto Shinkai-style picture performance.

The use of channels

When rendering into a map, we need to add some channels to the rendering elements to help us post-process the scene. I added VRGI channels, VR lighting channels, VR reflection channels, VR shadow channels, VR highlight channels, and Z channel. The Z channel needs to test the distance of the camera in advance. It can be measured directly with a tape measure, or the camera's ambient range display can be turned on. The rendering results are as follows:

Creation Analysis Using 3D to Make 2D Style Scene 17Creation Analysis Using 3D to Make 2D Style Scene 17Creation Analysis Using 3D to Make 2D Style Scene 18 Creation Analysis Using 3D to Make 2D Style Scene 19 Creation Analysis Using 3D to Make 2D Style Scene 20 Creation Analysis Using 3D to Make 2D Style Scene 21

Adjust the color and composition

In the last step of color processing, you must first have a clear understanding of the overall picture effect processing ideas. Let's analyze the original picture of Makoto Shinkai first. "Koto no ha no niwa" uses the delicate design and delicate application of color elements to enhance the overall expression of the work. In the picture, the author uses a variety of green and gray with different purity and brightness. Multi-tones such as blue, white, and white are painted and painted. The crystal clear and colorful colors contrast with each other, forming the vivid art style of the film. The courtyard scene uses high-purity dark green forest leaves as the main thing, and the dark parts are generally biased to cool gray, so we must focus on these factors in the post-processing.

Creation Analysis Using 3D to Make 2D Style Scene 22

Select the color of the GI channel and the reflection channel for the superposition method, and select the soft light for the superposition method of the light channel. Adjust the opacity of the screen overlay according to the picture conditions. The Z channel is reserved, and then the center of the picture is brightened with warm colors. The colored sky map gives the original image a soft light overlay. The opacity is set to 50% to make the picture breathable. Then adjust the color balance, saturation, and curve of the overall picture to improve the overall color purity and contrast of the picture. Warm color filter, as shown below:

Creation Analysis Using 3D to Make 2D Style Scene 23

Next, use the Z channel to create the blue fog effect in the dark part at the top of the screen. Display the Z channel separately, adjust the color level to make the black and white obvious. Then, in the RGB channel, Ctrl + left mouse button to select the white selection area. One layer, fill it with blue-gray, and adjust the opacity as shown:

Creation Analysis Using 3D to Make 2D Style Scene 24

Create a new layer, use the radial gradient in the gradient to make a rainbow in the upper left corner, wipe out the desired shape, and then add a Gaussian blur to give the rainbow a foggy feel.

Creation Analysis Using 3D to Make 2D Style Scene 25

Next, create a soft light effect for the overall screen. Ctrl + Alt + Shift + E stamps all visible layers duplicates one layer and uses Image-Adjust- Threshold to change the image to black and white. Similarly, select the white part of the selection, Ctrl + J duplicates one layer, uses soft light for the superposition method, and gives a Gaussian blur with a value of 10, so that you can get a soft light effect that enhances the bright part of the overall picture, adding a depth of field effect, and the final effect is shown in the figure:

Creation Analysis Using 3D to Make 2D Style Scene 26

Fox Renderfarm hopes it will be of some help to you. It is well known that Fox Renderfarm is an excellent cloud rendering services provider in the CG world, so if you need to find a 3ds Max render farm, why not try Fox Renderfarm, which is offering a free $25 trial for new users? Thanks for reading!
